Netis P124GH PoE Switch with 24 PoE Ports

The Netis P124GH PoE Switch powers and connects twenty-four devices through ordinary network cables. Moreover, its generous power budget supports large camera systems and busy wireless networks. As a result, one switch replaces dozens of separate power adapters.

Two gigabit uplinks and SFP slots carry traffic to your recorder or core network. Furthermore, the steel case and fanless operation suit quiet equipment rooms. Therefore, large deployments stay tidy and dependable.

In addition, protection features guard every PoE port. Consequently, high-power devices run with confidence.

One Cable, Twenty-Four Powered Devices

Large sites struggle to find power outlets for every camera and access point. However, PoE removes that problem. Therefore, teams place devices wherever coverage matters most. Moreover, fewer cables mean cleaner ceilings and faster changes later.

The IEEE develops the 802.3af and 802.3at standards behind PoE. Likewise, this switch supports both. As a result, it powers compliant devices from many brands. Additionally, each port detects the connected device before it sends power.

Why the Netis P124GH PoE Switch Suits Large Deployments

Large deployments need many ports, plenty of power, and fast uplinks. Therefore, this unmanaged switch combines all three. Moreover, it works without software or configuration.

Twenty-Four PoE Ports With a Large Power Budget

Ports 1 to 24 supply data and power together at 10/100Mbps. Furthermore, each port delivers up to 30 W. Moreover, the 360 W total budget supports demanding devices such as PTZ cameras. For example, twenty-four devices drawing 15 W each fit comfortably. However, add up your device loads first to stay within the budget.

Gigabit Uplinks for Recorders and Routers

Two gigabit RJ45 uplinks move combined traffic to a recorder or router. Therefore, many camera streams reach their destination without slowing down. Additionally, non-blocking wire-speed forwarding keeps all ports moving at full rate. Consequently, a 12.8 Gbps switching capacity handles busy networks with ease.

SFP Slots for Fibre Links

Each gigabit uplink pairs with an SFP slot. Therefore, you can choose copper or fibre for each upstream link. Moreover, fibre carries data farther and resists electrical interference. The Fiber Optic Association offers helpful guidance on fibre cabling. As a result, distant buildings can join the same network.

Extend Mode for Longer Cable Runs

A mode setting switches between normal and extend operation. In extend mode, the switch supports longer cable runs than standard Ethernet allows. Therefore, far-off cameras in yards and car parks stay connected. However, check each device’s needs first, because extend mode lowers link speed.

Safeguards for Constant Operation

Large PoE networks run day and night. Therefore, this switch builds in several safeguards.

Power Protection Features

Over-current, over-voltage, and short-circuit protection guard the PoE ports. Additionally, soft start support eases the load from high-power devices. Moreover, sequential boot-up powers devices one after another. Consequently, a power outage recovery avoids a sudden surge across the whole switch.

Steel Case and Quiet Cooling

A sturdy steel case protects the internal parts. Furthermore, the fanless design removes fan noise from offices and equipment rooms. Meanwhile, LED indicators show power, link activity, and PoE status for every port. As a result, spotting a problem port takes only a glance.

Netis P124GH PoE Switch Technical Specifications

The list below summarises the main hardware details.

• Brand: Netis
• Model: P124GH
• Device type: Unmanaged PoE switch
• PoE ports: 24 x 10/100Mbps RJ45 (ports 1 to 24)
• Uplink ports: 2 x 10/100/1000Mbps RJ45
• SFP slots: 2 x 1000Mbps SFP, paired with the RJ45 uplinks
• PoE standards: IEEE 802.3af and IEEE 802.3at
• Maximum power per PoE port: 30 W
• Total PoE power budget: 360 W
• Ethernet standards: IEEE 802.3, 802.3i, 802.3u, 802.3x
• Switching capacity: 12.8 Gbps
• MAC address table: 16K entries
• Forwarding: Store and forward with non-blocking wire speed
• Duplex: Full duplex via IEEE 802.3x and half duplex via backpressure
• Cable detection: Auto MDI/MDIX on all ports
• Modes: Normal mode and extend mode
• Protection: Over-current, over-voltage, short-circuit, soft start, and sequential boot-up
• Housing: Steel
• Cooling: Fanless
• Mounting: Desktop or rack-mountable
• Indicators: Power, link/activity, and PoE status LEDs
• Management: Unmanaged, plug and play

For official product details, visit the Netis Systems website.

Practical Use Cases

Netis P124GH PoE Switch for Large Camera Systems

Security networks often run twenty or more cameras. Therefore, one switch can power an entire floor or warehouse. Moreover, 30 W per port supports PTZ models that need extra power. In addition, Dahua Technology publishes PoE guidance for its network cameras. Consequently, planning power and cabling becomes much easier.

Recording Rooms and NVR Storage

Cameras generate large amounts of video every day. Therefore, gigabit uplinks carry that traffic to the recorder without delay. Likewise, teams can keep footage on dependable storage for later review. Additionally, a tidy switch keeps the recording room organised.

Security Control Rooms

Operators watch live feeds from many cameras at once. Therefore, stable network links matter as much as the cameras themselves. Moreover, clear monitors help staff spot details quickly. As a result, security teams respond faster to events.

Hotels, Schools, and Offices

Large buildings need cameras, Wi-Fi, and phones on one network. In that case, a 24-port PoE switch powers all three from a single cabinet. Furthermore, ceiling access points gain power without nearby sockets. Meanwhile, the quiet body suits busy back offices.

Netis P124GH PoE Switch Compatibility

This switch works with any IEEE 802.3af or 802.3at powered device. Moreover, standard Ethernet devices connect to the same ports and receive data only. Because PoE detection runs first, those devices stay safe.

Cameras, Phones, and Access Points

IP cameras, VoIP phones, and wireless access points all work well here. However, each device must stay within 30 W per port. Likewise, the combined draw must stay under the 360 W budget. Additionally, the PoE ports run at 10/100Mbps, which suits most camera streams.

Routers, Recorders, and Core Switches

The uplinks connect to routers, recorders, and larger switches. Furthermore, Auto MDI/MDIX adapts to the cable type automatically. Therefore, straight and crossover cables both work. You can also add other networking products such as routers and access points to complete the network. However, this unmanaged unit offers no VLAN or remote management features.

Quality Standards You Can Rely On

Customers trust Aiconic Computers for PoE hardware that follows recognised standards. This switch complies with IEEE 802.3af and 802.3at, so it delivers dependable power and data. Furthermore, the steel case, protection features, and large power budget reflect solid build quality. We stand behind product quality fully. In addition, we process orders quickly, so customers receive their products promptly. As a result, businesses can power large camera and Wi-Fi networks without long waits.
