Netis ST106PDI-2-65 PoE Switch with 4 PoE Ports

SEO Optimized Product Description

Netis ST106PDI-2-65 PoE Switch with 4 PoE Ports

The Netis ST106PDI-2-65 PoE Switch delivers data and power through a single network cable. Moreover, it removes the need for a separate power adapter at every device. As a result, cameras and access points sit exactly where coverage matters most.

This compact unit offers four PoE ports and two uplink ports. Furthermore, it supports both IEEE 802.3af and 802.3at powered devices. Therefore, small offices and shops can build a tidy, powered network with ease.

In addition, the steel housing and fanless design suit quiet workspaces. Consequently, the switch fits comfortably on a desk or shelf.

Power and Data Over One Cable

Power over Ethernet changes how people plan a network. Instead of running mains cables, people run one network cable per device. Consequently, cabling stays simple and neat.

The IEEE standards organisation defines how PoE delivers power safely. Moreover, this switch follows both the 802.3af and 802.3at specifications. Therefore, it powers a wide range of compliant devices without adapters.

The 802.3at standard allows up to 30 W on each port. As a result, power-hungry devices such as PTZ cameras run reliably. Additionally, the built-in 65 W power supply removes the need for an external adapter. Likewise, the switch detects each powered device and supplies power only when needed.

Why the Netis ST106PDI-2-65 PoE Switch Suits Small Networks

Small networks need simple, dependable hardware. Therefore, this unmanaged switch works straight out of the box. Moreover, it needs no software or configuration. As a result, first-time network builders can connect devices with confidence.

Four PoE+ Ports for Powered Devices

Four 10/100 Mbps ports supply power and data together. In addition, each port delivers up to 30 W to a connected device. Consequently, one switch can feed several cameras and access points at once.

However, the total power budget stays at 65 W. Therefore, plan your device mix so the combined draw stays within that limit.

Two Uplink Ports for Easy Expansion

Two dedicated uplink ports connect the switch to a router or main switch. Furthermore, they let you extend the network as your needs grow. You can pair this unit with other networking products such as routers and wireless access points. Meanwhile, the uplinks keep traffic flowing smoothly to the rest of your network.

Built for Stable Power Delivery

Reliable power matters most for devices that run all day. Therefore, Netis builds several protections into this switch. For example, surge protection shields connected devices from sudden voltage spikes. Similarly, overload protection stops the ports from supplying more power than they safely can. Additionally, standard IEEE detection keeps non-PoE devices safe on the same ports. Cisco offers helpful networking resources that explain PoE power budgeting in more detail.

Secure Cables and Silent Cooling

An attached safety lock holds each cable firmly in place. Consequently, accidental disconnections become far less likely. Moreover, the steel housing helps dissipate heat efficiently. Because the design is fanless, the unit also runs in silence. Therefore, it suits offices, shops, and homes alike.

Netis ST106PDI-2-65 PoE Switch Technical Specifications

Below, you can review the key hardware details at a glance.

• Brand: Netis
• Model: ST106PDI-2-65
• Switch type: Unmanaged Fast Ethernet PoE switch
• Total ports: 6
• PoE ports: 4 x 10/100 Mbps (ports 1 to 4)
• Uplink ports: 2 x 10/100 Mbps
• PoE standards: IEEE 802.3af and IEEE 802.3at
• Maximum power per PoE port: 30 W
• Total PoE power budget: 65 W
• Ethernet standards: IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3x flow control
• Cable detection: Auto MDI/MDIX
• Extend mode: DIP switch for transmission up to 250 m on PoE ports
• Power supply: Built-in 65 W
• Housing: Steel
• Cooling: Fanless, silent operation
• Protection: Surge protection and overload protection
• Setup: Plug and play with no configuration

For further product information, visit the Netis Systems website.

Practical Use Cases

Netis ST106PDI-2-65 PoE Switch in Surveillance Setups

IP cameras form the most common use for this switch. Therefore, shops and homes can power three or four cameras through one unit. Moreover, extend mode reaches cameras mounted far from the switch. As a result, gates, car parks, and yards come under watch. Consequently, a single cable run per camera keeps the layout tidy. In addition, camera makers such as Axis Communications publish PoE requirements for their models.

Wireless Access Points and VoIP Phones

Access points need power in ceilings and corners. Consequently, PoE removes the need for nearby wall sockets. Likewise, VoIP phones receive power through the same desk cable. Therefore, desks stay free from extra adapters. Additionally, a clean layout helps office staff stay productive.

Retail Shops, Cafes, and Small Offices

Small businesses often need cameras and Wi-Fi without complex wiring. In that case, this switch handles both jobs from one compact box. Furthermore, owners can keep recorded footage on dependable storage devices. Meanwhile, the quiet fanless body suits customer-facing counters.

Home Offices and Smart Homes

Home users also benefit from powered network ports. For instance, a PoE camera can watch the front door while an access point covers the garden. Similarly, a home office can run a phone and an access point together. Overall, one small unit replaces a tangle of power cables.

Netis ST106PDI-2-65 PoE Switch Compatibility

This switch works with any standards-compliant powered device. Moreover, it connects regular Ethernet devices through the same ports. However, those regular devices simply receive data and no power.

Cameras, Phones, and Access Points

IP cameras, VoIP phones, and wireless access points all work well here. However, each device must stay within 30 W per port. Likewise, the combined load must stay under 65 W. In addition, you can pair cameras with video management softwares to record and review footage easily.

Routers and Upstream Switches

The uplink ports connect to routers, firewalls, and larger switches. Additionally, Auto MDI/MDIX detects the cable type automatically. Therefore, you can use straight or crossover cables without worry. Because the switch supports Fast Ethernet, links run at up to 100 Mbps. Moreover, flow control support helps manage busy traffic.

Quality Standards You Can Rely On

Customers trust Aiconic Computers for networking hardware that meets recognised standards. This PoE switch follows IEEE 802.3af and 802.3at, so it delivers dependable power. Furthermore, its steel housing, surge protection, and overload protection reflect solid build quality. Likewise, the safety lock and fanless design show careful engineering. We stand behind product quality fully. In addition, we process orders quickly, so customers receive their products promptly. As a result, businesses and homes can power their cameras and access points without long waits.
